Основные характеристики
Basic data | |
Series | 3B |
Operating principle | Reflection principle |
Application | Detection of high-gloss or polished surfaces |
Special version | |
Special version | Autocollimation, Teach input |
Optical data | |
Operating range | 0 ... 2 m |
Operating range limit | 0 ... 3 m |
Light source | Laser, Red |
Laser class | 1, IEC/EN 60825-1:2007 |
Light spot size [at sensor distance] | 2 mm |
Electrical data | |
Protective circuit | Polarity reversal protection, Short circuit protected |
Performance data | |
Supply voltage UB | 10 ... 30 V, DC |
Residual ripple | 0 ... 15 %, From UB |
Open-circuit current | 0 ... 15 mA |
Inputs | |
Number of teach inputs | 1 Piece(s) |
Outputs | |
Number of digital switching outputs | 1 Piece(s) |
Switching output 1 | |
Switching element | Transistor, Push-pull |
Switching principle | Light switching (PNP)/dark switching (NPN) |
Timing | |
Switching frequency | 2,000 Hz |
Response time | 0.25 ms |
Connection 1 | |
Function | Voltage supply, Signal IN, Signal OUT |
Type of connection | Cable |
Cable length | 2,000 mm |
Number of conductors | 4 -wire |
Mechanical data | |
Dimension (W x H x L) | 11 mm x 32 mm x 17 mm |
Housing material | Plastic |
Plastic housing | PC-ABS |
Lens cover material | Plastic / PMMA |
Net weight | 50 g |
Type of fastening | Through-hole mounting |
Operation and display | |
Operational controls | Teach button |
Environmental data | |
Ambient temperature, operation | -40 ... 55 °C |
Certifications | |
Degree of protection | IP 67 |
Protection class | III |
Certifications | c UL US |
Standards applied | IEC 60947-5-2 |
Classification | |
Customs tariff number | 85365019 |
eCl@ss 5.1.4 | 27270902 |
eCl@ss 8.0 | 27270902 |
eCl@ss 9.0 | 27270902 |
eCl@ss 10.0 | 27270902 |
eCl@ss 11.0 | 27270902 |
ETIM 5.0 | EC002717 |
ETIM 6.0 | EC002717 |
ETIM 7.0 | EC002717 |
