Производитель: Leuze Electronic (Германия)
Обработка заказа в течение дня
Возможен выезд специалиста на производство
Техническая консультация и квалифицированная помощь в подборе оборудования
Предоставление технической документации
Производитель: Leuze Electronic (Германия)
Основные характеристики
Basic data | |
Series | 3C |
Operating principle | Diffuse reflection principle with background suppression |
Special version | |
Special version | 2 independent switching outputs |
Optical data | |
Black-white error | < ± 3 mm |
Operating range | 0.01 ... 0.15 m |
Adjustment range | 30 ... 150 mm |
Light source | LED, Red |
Light spot size [at sensor distance] | 10 mm x 10 mm [100 mm] |
Electrical data | |
Protective circuit | Polarity reversal protection, Short circuit protected |
Performance data | |
Supply voltage UB | 12 ... 30 V, DC, Incl. residual ripple |
Residual ripple | 0 ... 15 %, From UB |
Open-circuit current | 0 ... 25 mA |
Outputs | |
Number of digital switching outputs | 2 Piece(s) |
Switching output 1 | |
Switching element | Transistor, Push-pull |
Switching principle | Light switching (PNP)/dark switching (NPN) |
Switching output 2 | |
Switching element | Transistor, Push-pull |
Switching principle | Light switching (PNP)/dark switching (NPN) |
Timing | |
Switching frequency | 750 Hz |
Response time | 0.66 ms |
Connection 1 | |
Function | Signal OUT, Voltage supply |
Type of connection | Connector |
Thread size | M8 |
Material | Metal |
No. of pins | 4 -pin |
Mechanical data | |
Dimension (W x H x L) | 11.4 mm x 34.2 mm x 18.3 mm |
Housing material | Plastic |
Plastic housing | PC-ABS |
Lens cover material | Plastic / PMMA |
Net weight | 10 g |
Type of fastening | Via optional mounting device, Through-hole mounting |
Compatibility of materials | ECOLAB |
Operation and display | |
Operational controls | Teach button |
Environmental data | |
Ambient temperature, operation | -40 ... 60 °C |
Certifications | |
Degree of protection | IP 69K, IP 67 |
Protection class | III |
Certifications | c UL US |
Standards applied | IEC 60947-5-2 |
Classification | |
Customs tariff number | 85365019 |
eCl@ss 5.1.4 | 27270904 |
eCl@ss 8.0 | 27270904 |
eCl@ss 9.0 | 27270904 |
eCl@ss 10.0 | 27270904 |
eCl@ss 11.0 | 27270904 |
ETIM 5.0 | EC002719 |
ETIM 6.0 | EC002719 |
ETIM 7.0 | EC002719 |
