Производитель: Leuze Electronic (Германия)
Обработка заказа в течение дня
Возможен выезд специалиста на производство
Техническая консультация и квалифицированная помощь в подборе оборудования
Предоставление технической документации
Производитель: Leuze Electronic (Германия)
Основные характеристики
Basic data | |
Series | 5 |
Operating principle | Diffuse reflection principle |
Optical data | |
Operating range, white 90% | 0.001 ... 0.215 m |
Operating range, gray 50% | 0.001 ... 0.19 m |
Operating range, gray 18% | 0.003 ... 0.15 m |
Operating range, black 6% | 0.005 ... 0.125 m |
Operating range limit, white 90% | 0.001 ... 0.28 m |
Operating range limit, gray 50% | 0.001 ... 0.245 m |
Operating range limit, gray 18% | 0.003 ... 0.19 m |
Operating range limit, black 6% | 0.005 ... 0.16 m |
Light source | LED, Infrared |
Electrical data | |
Protective circuit | Short circuit protected, Polarity reversal protection |
Performance data | |
Supply voltage UB | 10 ... 30 V, DC, Incl. residual ripple |
Residual ripple | 0 ... 15 %, From UB |
Open-circuit current | 0 ... 20 mA |
Outputs | |
Number of digital switching outputs | 2 Piece(s) |
Switching output 1 | |
Switching element | Transistor, PNP |
Switching principle | Light switching |
Switching output 2 | |
Switching element | Transistor, PNP |
Switching principle | Dark switching |
Timing | |
Switching frequency | 500 Hz |
Response time | 1 ms |
Connection 1 | |
Function | Signal OUT, Voltage supply |
Type of connection | Connector |
Thread size | M8 |
Material | Plastic |
No. of pins | 4 -pin |
Mechanical data | |
Dimension (W x H x L) | 14 mm x 32.5 mm x 20.2 mm |
Housing material | Plastic |
Plastic housing | ABS |
Lens cover material | Plastic |
Net weight | 20 g |
Operation and display | |
Operational controls | Teach button |
Environmental data | |
Ambient temperature, operation | -40 ... 60 °C |
Certifications | |
Degree of protection | IP 67 |
Protection class | III |
Certifications | c UL US |
Standards applied | IEC 60947-5-2 |
Classification | |
Customs tariff number | 85365019 |
eCl@ss 5.1.4 | 27270903 |
eCl@ss 8.0 | 27270903 |
eCl@ss 9.0 | 27270903 |
eCl@ss 10.0 | 27270903 |
eCl@ss 11.0 | 27270903 |
ETIM 5.0 | EC001821 |
ETIM 6.0 | EC001821 |
ETIM 7.0 | EC001821 |
